U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace

I'm Online Chat Now

U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace

U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace
U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace

Large Image :  U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace

Product Details:
Place of Origin: China
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD10/piece
Packaging Details: Strong wooden box for Global shipping
Delivery Time: 5-20work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 pieces per month

U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace

Description
Highlight:

Silicon Carbide Heating Element Rod

,

Furnace Silicon Carbide Heating Element Rod

,

W Type Sic Heating Elements

U W I type High temperature sic heater silicon carbide heating element rod for furnace

Product Description
U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace 0
silicon carbide SiC heating elements ( heater )
1) Material: Good quality green SiC poeders.
2) Product: A kind of non-metal high temperature electric heating element.
3) Production Process: Made into blank, silicided under high temperature and re-crystallized.
4) Usage: It is widely used in various high temperature laboratory furnace and other electric heating
devices, such as in the industries of magnet, ceramics, power metallurgy, glass, and metallurgy.
5) Character: Higher temperature, antioxidation, anticorrosion, increasing temperature fast, low
coefficient of thermal expansion and so on.
6) Heater Specifications and Resistance Range

Physical properties of elements:
Specific gravity
Bend strength
Hardness
Tensile Strength
Porosity rate
Radiancy
2.6~28g/cm3
>300kg
>9MOH'S
>150kg/cm3
<30%
0.85
The linear expansion coefficient, heat conductivity and specific heat of element will change along withtemperature change. And the relational data are the follows:
Temperature (c)
Linear expansion coefficient (10m/c)
Heat conductivity (kcal/M hrc)
Speciic heat (cal/g'c)
o
/
/
0.148
300
3.8
/
/
400
/
/
0.255
600
4.3
14-18
/
800
/
/
0.294
900
4.5
/
/
1100
/
12-16
/
1200
4.8
/
0.325
1300
/
10-14
/
1500
5.2
/
/

silicon carbide heating element.

Silicon carbide element use in construction, ceramic firing, float glass production, melting of non-ferrous metals, sintering,
brazing, and other applications that require operating temperatures of up to 1625°C. Heating elements composed of silicon carbide
are typically shaped as rods, tubes, or bars with single or multiple legs and metallized Aluminum extremities; other forms include
dumbbells and double or single spirals. Our standard heating elements sizes range between 0.5 to 3 inches in diameters and 1 to 10
feet in length. Custom shapes and sizes are also available by request. Silicon carbide heating elements are generally immediately
available in most volumes. American Elements also offers other forms of Silicon Carbide such as bricks, foam, honeycomb, powder
(including micron and submicron powders), micronwhiskers, nanoparticles, sponges, sputtering targets, and wool. Additional
technical, research and safety (MSDS) information is available.
U W I Type High Temperature Sic Heater Silicon Carbide Heating Element Rod For Furnace 1



High Temperature SiC Heating Elements , 1400C Silicon Carbide Rod 1
