1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace

1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace

Large Image :  1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace

Product Details:
Place of Origin: China
Payment & Shipping Terms:
Minimum Order Quantity: 1/pcs
Price: 5/usd/pcs
Packaging Details: Strong wooden box for Global shipping
Delivery Time: 3workdays
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000/pcs/month
Contact Now

1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace

Description
Highlight:

Silicon Carbide Sic Heating Element

,

High Temperature Resistance Sic Heating Element

,

Double Spiral Sic Heating Element

Products Description
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 0
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 1
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 2
Silicon carbide heating element is a non-metallic high-temperature heating element. It is made of high-quality green silicon carbide as the main material, made into blanks, siliconized at high temperature, and recrystallized. It is the most popular economical heating element, capable of operating in hot and harsh environments.
Specification
Outer Diameter
(OD, mm)
Hot zone
(HZ, mm)
Cold zone
(CZ, mm)
Overall length
(OL, mm)
Range of resistance
(ohms)
8
100-300
60-200
240-700
2.1-8.6
12
100-400
100-350
300-1100
0.8-5.8
14
100-500
150-350
400-1200
0.7-5.6
16
200-600
200-350
600-1300
0.7-4.4
18
200-800
200-400
600-1600
0.7-5.8
20
200-800
250-600
700-2000
0.6-6.0
25
200-1200
250-700
700-2600
0.4-5.0
30
300-2000
250-800
800-3600
0.4-4.0
35
400-2000
250-800
900-3600
0.5-3.6
40
500-2700
250-800
1000-4300
0.5-3.4
45
500-3000
250-750
1000-4500
0.3-3.0
50
600-2500
300-750
1200-4000
0.3-2.5
54
600-2500
300-750
1200-4000
0.3-3.0
Note: Specification above are parts of our products for your reference, and we can manufacture according to your special specification.
Details Images
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 3
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 4
Types
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 5
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 6
Outer Diameter: OD, (mm) Hot Zone Length: HZ, (mm)
Code Zone Length: CZ, (mm) Overall Length: OL, (mm)
Shank Spacing: A, (mm) Bridge: D, (mm)
Our Company
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 7
1500~1625°C Degree Double Spiral Sic Element High Temperature Resistance Silicon Carbide Heating Element For Furnace 8
