Product Details:
|
| Application: | Computed Tomography (CT) Positron Emission Computed Tomography (PET) Single Photon Emission Computed Tomography (SPECT) Particle Accelerator Laser And LED Lighting | Products: | Ce:luag |
|---|---|---|---|
| Advantage: | Good Mechanical And Chemical Stability | Diameter: | Φ3-40mm |
| Highlight: | Fast Attenuation Scintillator Crystal,Medical Imaging Scintillator Crystal,CT Scintillator Crystal |
||
CE: luage: luag is an excellent scintillator with fast attenuation (80ns), high light yield and 510nm emission peak, which is equivalent to the sensitivity and good mechanochemical stability of industrial silicon CCD detector. The crystal can be widely used in imaging screen, LED lighting and laser lighting, medical imaging and other fields.
Main advantages:
high-density
The decay time is short
Non hygroscopicity
Good mechanical and chemical stability
Application:
Computed tomography (CT)
Positron emission computed tomography (PET)
Single photon emission computed tomography (SPECT)
Particle accelerator
Laser and LED lighting
Material properties
| Molecular formula | Ce:Lu3Al5O12 |
|
Emission peak |
510nm |
| Lattice constant | a=11.914Å |
| Density | 6.73g/cm³ |
| Hardness | 8.5 Mohs |
| Melting point | 1970℃ |
|
reflection coefficient |
1.84 |
| Expansion coefficient | 8.8*10-6/℃ |
| Decay time | 80ns |
| Energy resolution | <8% |
Technical parameter
| Crystal orientation | <0.5° |
|
Diameter tolerance |
±0.05mm |
|
Parallelism |
<30″ |
| Perpendicularity | <15′ |
| Chamfering | <0.1*45° |
| verticalityMaximum size | Maxψ60mm |
